Pte Bottle Packing Coconut Juice Production Line 500L Per Hour

Place of Origin china
Brand Name sss
Model Number customzied
Minimum Order Quantity 1
Price usd200000
Packaging Details standard export packing
Delivery Time 90
Payment Terms L/C, T/T
Supply Ability 20sets/y

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Item 500L Per Hour Pte Bottle Packing Coconut Juice Production Line Input Green Coconut
Output Coconut Juice Capacity 500L/h
Fetaure Turnkey Projetc End Product Packing Pte Bottle
High Light

500L Per Hour Coconut Juice Production


Coconut Juice Production Line


500L/Hour Coconut Juice Production

Leave a Message
Product Description

500L Per Hour Pte Bottle Packing Coconut Juice Production Line


no item specification
1 Cutting machine

Ø used for slicing coconut juice and breaking the shell. The cutting is done automatically by machine, which truly replaces manual labor.

Ø grade 304 stainless steel

Ø Put the coconut horizontally on the baffle of the conveyor chain, and lift the coconut to the bottom of the dial frame. The top of the machine is equipped with a fixed blade, so that the coconut can interact between the blade and the dial frame. Cut in half by force. The half-cut juice flows into the juice hopper, and the coconut shells are introduced into the next process through the bar installed above the juice hopper.

2 Duplex filter

Ø Rated flow: 1T/H

Ø Filtration precision: 30um-1mm (optional standard specification)

3 cache jar

Ø volume: 500L

Ø 304 stainless steel material;

Ø Single-layer upper and lower cone-bottom structure;

Ø Stainless steel plate thickness: 3mm

Ø With stirring

Ø The outer surface adopts wire drawing board;

Ø High and low liquid level control;

Ø Conical top and cone bottom structure, including manhole, vent cap, cleaning ball, water inlet, material inlet and outlet, visual sight glass;

Ø The inlet and outlet adopt anti-foam and anti-swirl structure;

4 Material pump

Ø Flow: 1M3/H;

Ø Head 24m;

Ø Stainless steel material

Ø Power: 0.75kw


UHTTubular Sterilizer


Ø Special tubular structure, specially used for juice materials;

Ø Production capacity: 0.5T/H;

Ø Material inlet temperature: 40℃~50℃;

Ø The material outlet temperature is less than 40℃;

Ø Sterilization temperature: 95℃~121℃;

Ø Sterilization time: 10S;

Ø The main features of the system are as follows:

Ø One screw pump, one hot water pump, one CIP pump

Ø Front 100L material buffer tank;

Ø Plate Heat Exchanger, sealed water tank with sterilization pump

Ø Independent control cabinet, IP protection, man-machine interface PLC

Ø Siemens PLC, Siemens touch screen

Ø Schneider, Omron low voltage components, Japan Fuji temperature controller

Ø Taiwan AirTAC pneumatic components

Ø Steam valve group: pressure reducing valve, filter, regulating valve, globe valve, steam trap

6 Bottle loading platform Ø SS304 material

air delivery


Ø SS304 for frame

Ø Matching fan


Three-in-one bottle washing, filling and sealing


Ø The whole machine is made of 304 stainless steel, and the main motor is an imported variable frequency motor

Ø Wash bottle with pressure gauge

Ø Applicable bottle type: Diameter: Φ60-96mm.

Ø Applicable bottle height: 180-250mm

Ø The filling range is 300-500ml (the bottle mouth is the same, the locator must be changed)

Ø Filling accuracy: ±2mm

Ø Filling principle: micro negative pressure filling

Ø Can realize CIP cleaning function

Ø The inside of the rotating head is a magnetic mechanism, and the torque can be adjusted to ensure the qualified rate of sealing.

Ø Siemens PLC, Siemens touch screen

Ø Schneider low-voltage control appliances.

Ø Capping defect rate≤0.2%

Ø The efficiency of the whole machine is more than 95%



Pte Bottle Packing Coconut Juice Production Line 500L Per Hour 0
