Fresh Apple Puree And Paste Production Line Aseptic Packing 2t/H Input

Place of Origin china
Brand Name sss
Model Number customzied
Minimum Order Quantity 1
Price 399000
Packaging Details standard export packing
Delivery Time 120
Payment Terms L/C, T/T
Supply Ability 10sets/year
Product Details
Item Name 2t/happle Production Line Fruit Pulp Inout Fresh Apple
Output Apple Puree Capacity 2t/h
Feature Turnkey Project Product Packing Aseptic Big Bag
High Light

Aseptic Packing Apple Puree Production Line

,

Aseptic Packaging Apple Puree Production Line

,

Apple Puree And Paste Production Line

Leave a Message
Product Description

Apple Puree And Paste Production Line Fresh Apple 2t/H Input Fruit Juice Production Line

Apple Puree Production Line



2t/h 220L aseptic big bag packing apple puree production line consists of apple pretreatment unit,apple puree making, Sterilzation system,apple puree and paste packing,control system etc.



UHT tubular sterilizer
Ø Special tubular structure, specially used for juice materials;
Ø Capacity: 2T/H;
Ø Material inlet temperature: 40℃~50℃;
Ø The material outlet temperature is less than 40℃;
Ø Sterilization temperature: 95℃~121℃;
Ø Sterilization time: 10S;
Ø Cooling water temperature <30℃
Ø The main features of the system are as follows:
Ø Rated processing capacity
Ø Cooling water consumption: 30 tons/hour, the water temperature is less than 30 degrees Celsius;
Ø Steam consumption: 600kg/H
Ø Compressed air; 1m3/min
Single head aseptic filling machine
Ø Output: 2T/H
Ø Online control with front-end sterilizer to realize CIP and SIP
Ø This aseptic filling machine is mainly composed of aseptic filling head (1 piece), operating system, man-machine control system,
weight measurement and workbench. The packaging bag adopts aluminum-plastic composite aseptic bag, and the whole process is
carried out in a sterile environment. The main features are as follows:
Ø Human-machine interface control, real-time display and control of weight;
Ø Equipped with manual and automatic control systems;
Ø Automatic weight measurement deviation is 1-2%;
Ø Can be linked with the sterilizer to do CIP and SIP;
Ø To achieve the purpose of aseptic filling, the final product can be stored for 18 months at normal temperature
