Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine

  • Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine
  • Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine
  • Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine
Place of Origin china
Brand Name SSS
Certification CE / ISO
Model Number SSS-BPD400
Minimum Order Quantity 1set
Price $8,800-$10,500
Packaging Details polyWood packaging
Delivery Time 30day
Payment Terms L/C, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 10set

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Supermarket Factory Color Silver
Material 304 Stainless Steel Powe 22kw
Voltage 380V Weight 860kg
Warranty 1year Feature Low Energy High Speed
Leave a Message
Product Description

Smart PLC Control Shawama Roll Making Machine Tortilla Making Equipment

Arabic Pita Production Line starts from heat pressing process after putting divided tortilla dough balls. The dough balls would be first evenly flattened by the pressing & heating system, and then baked through oven, which bakes both sides of the tortilla until delightfully browned in spots. And then into the cooling line To facilitate packing, the tortilla production line is able to stack required quantity of final products in a pile.



TECHNICAL DATA :

Model BP400 (Components:Head unit •Press •Oven • Cooler BP400-2(Double Extruders) (Components:Head unit •Press •Oven •Cooler)
Heating method Electric Electricity
Hot Press Plate size 350*450 mm 350*650 mm
Power supply 380V/ three Phase/ Rated Power21KW/Actual Power 15KW 380V/ three Phase/ Rated Power28KW/Actual Power 17KW
Gas consumption 3.0 m³/h - Natural Gas
2.4 kg/h - LP Gas		 3kW/H
Tortilla Dia. 100-300 mm 100-300 mm
Tortilla Thickness 0.5-2 mm 0.5-2 mm
Tortilla per hour 600-1000 pcs 800-2000 pcs/ H
Machine Dimension 4993*930*1482 mm 5000*930*1490 mm
Weight N.W. :680KG, G.W.: 960KG N.W. :680KG, G.W.: 960KG



Features:

  • 1. The PLC touch screen: Taiwan Delta

    2. Frequency converter: Taiwan Delta

    3. Motor: Dongbang motor

    4. Electrical appliances: Chint electrical

    5. Belt is food-grade blue PU belt

    6. Roller material is food-grade PE material

    7. The material of the above equipment is stainless steel and aluminum profile

Two heads:



Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine 0



Hydraulic press:



Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine 1

package:

Smart PLC Control Shawama Roll Making Machine Tortilla Making Machine 2
