250ml Brick Shape Automatic Packing Machine 7000 Pack Per Hour

  • 250ml Brick Shape Automatic Packing Machine 7000 Pack Per Hour
  • 250ml Brick Shape Automatic Packing Machine 7000 Pack Per Hour
Place of Origin china
Brand Name sss
Model Number customzied
Minimum Order Quantity 1
Price usd380000
Packaging Details standard export packing
Delivery Time 40
Payment Terms L/C, T/T
Supply Ability 10sets/y

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Item 250ml 7000pack Per Hour Brick Shape Automatic Packing Machine Packing Type Brick
Volume 250-1000ml Packing Speed 3000-7000pcs/h
Feature Turnkey Project Application Juice Packing
High Light

250ml Bottle Automatic Packing Machine

,

Brick Shape Automatic Packing Machine

,

7000pack/H Automatic Packing Machine
Leave a Message
Product Description

250ml 7000pack Per Hour Brick Shape Automatic Packing Machine



item

 specification
Aseptic carton packaging machine

Capacity:7000bag/j

Pack volume:400ml(±1.5%ml)

Dimension:4690-2540-3670mm

Weight:5000kgs

Voltage:380v±10%, 50hz

Power:35kw

Connection:thread mouth 1/2inch

Air consumption:500±100L/min(0.6-0.7mpa)

Purified water consumption:15L/min(0.3-0.45mpa,<20C)

Steam consumption:4.5kg/h(130±5C,0.17±0.03MPA)

Connection:G 1/2,thread

Hydrogen peroxide consumption:0.6-1.0L/min(density30-50%)

Operation system:HM5

Output conveyor:keel chain

Filling material temp:15-25C

Filling material viscosity:<30CPD

Connection:2S SMS thread

Connection pressure0-150±10kpa

Container shape:brick

Packing material:roll cardboard

Temp:19.4-25C

Subcontracting device
conveyor

Rack body is made of 304 stainless steel,

Conveying adopts plastic chain plate

Height and effective width of conveying can be adjusted
Pipe sticking machine

Capacity:7000pcs/h

Dimension:1600*850*1150mm

Weight:250kgs

Voltage:380v±10%, 50/60hz

Power:4.5KW

Air consumption:100L/min(0.6-0.7mpa)





250ml Brick Shape Automatic Packing Machine 7000 Pack Per Hour 0



Company Profile

SSS Food Machinery Technology Co., LTD is a leading supplier of food processing equipment in China.We are able to provide complete turnkey project solution for intelligent processing equipment.We are mainly specialized in fruit and vegetables processing line for puree,juice,jam,dried fruit, powder,fruit wine & vinegar,fermented beverage,ect .Also the related stand-along equipment with superior quality,competitive price and professional service.SSS has a complete team from R&D design, production, quality inspection,process guidance, with more than 20 years’ professional experience in this field.



2. processing equipment and quality assurance

3kw double-table high-power laser cutting machine 1SET CNC spark discharge machine, 6SETS
Drilling machine ,Z3025×10/1 Z3032×10, 8SETS CNC wire cutting, Japan FANUC, 10SETS
Automatic milling machineX60-W,3SETS Grinding machine PFG4080AH,5SETS
Lathe 6250-6150, 10SETS Spinning machine,2SETS
Automatic polishing machine,2SETS Spheronizing machine,2SETS
Shearing machine QC12Y6-2500,2SETS Folding machine WEHK-250/3100,3SETS
automatic welding machine,3SETS electric welding machine315A,50SETS
TIG welding machine200A,80SETS TIG welding machine300A,150SETS


250ml Brick Shape Automatic Packing Machine 7000 Pack Per Hour 1
