Dried Fruit Mango Processing Line One Ton Per Day Bag Packing

Place of Origin china
Brand Name sss
Model Number customzied
Minimum Order Quantity 1
Price usd200,000
Packaging Details standard export packing
Delivery Time 120
Payment Terms L/C, T/T
Supply Ability 5sets/m

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Product One Ton Per Day Bag Packing Dried Mango Fruit Processing Line Input Fresh Mango
Output Sliced Dried Mango Capacity 1t/d
Feature Turnkey Project Packing Bag
High Light

1Ton/Day Mango Processing Line


Dried Mango Processing Line


Sliced Dried Mango Processing Line

Leave a Message
Product Description


One Ton Per Day Bag Packing Dried Mango Fruit Processing Line



Ø 1T/H

Ø Suitable for slicing of root vegetables and block vegetable raw materials, such as sweet potato, taro, artichoke, etc.

Ø The whole machine is made of national standard 304 stainless steel plate, which is corrosion-resistant and meets the needs of food hygiene.

Ø Raw material thin slices,min thickness of 1mm

Ø Centrifugal cutting principle, the cut surface is smooth and flat, without damaging the raw material tissue.


Ø Capacity: 500L;

Ø Ø Vacuum degree: -0.08MPa;

Ø ØThree-layer tank design;

Ø ØUsing steam for heat exchange;

Ø ØThe vacuum pump adopts domestic brand vacuum pump;

Ø Ø Steam-water separator;

Ø ØPipeline valve;

Ø ØUsing SUS304 stainless steel;

Ø Ø Dimensions: 3600*2000*1800mm (length*width*height);

Ø Weight: 500KG

drying room

Ø 1000kg/day

Ø Ø304 stainless steel

Ø Ø Power: 80kw

Ø The difference between the drying room and the belt dryer is that the drying room is troublesome to operate, and it needs to be manually loaded and then pushed into the drying room.

Packing & conveying

Ø Output: 200KG/H

Ø SUS stainless steel

Ø The mesh belt adopts PTFE cloth conveyor belt

Ø Power: 1.5KW

Ø Dimensions: 4500*400*1100mm

Ø Weight: 120kg

Microwave Sterilizer

Ø Capacity: 200KG/H

Ø Using SUS304 stainless steel

Ø Length 5000mm*width 600*height 1500Steam valve group: pressure reducing valve, filter, regulating valve, globe valve, steam trap

Automatic packaging weighing conveyor line, coding

Ø 1. Weighing range: 30-1000g

Ø 2. Single bucket volume: 1.3 L

Ø 3. Weighing accuracy: 0.1-1.0g

Ø 4. Weighing speed: 30-130bag/min

Ø 5. Drive mode: stepper motor

Ø 6. Power supply: 220V/50HZ

Ø 7, Power: 2000W

Ø Vertical packaging machine

Ø 1. Bag size: width 55-200mm

Ø Length 60-300mm

Ø Equipment quotation includes one bag size mold,

Ø 2. Packing speed: 40-75bag/min

Ø 3. Power supply: 220V/50HZ

Ø 4. Power: 3.0kw

Ø 5. Compressed air 6-8kg

Ø 6. Air consumption: 0.4m3/min

Ø 7. Weight 800kg

Ø 1. Power: 60w

Ø 2. Conveying speed 100bag/min

Ø 3. Power 220V/50HZ

Ø 4. Weight 60kg

Ø Stainless steel Z-shaped material conveying equipment

Ø (including silo vibration)

Ø 1. Lifting capacity: 7200L/h

Ø 2. Single bucket volume: 1.84L

Ø 3. Power supply: 3 phase 380V, 50-60 Hz

Ø 8.4, Power: 750W

Ø ~ length 6000mm* width 1800* height 2800
