1 - 100 Ton Per Hour Mango Processing Line Customized

Place of Origin china
Brand Name sss
Model Number customzied
Minimum Order Quantity 1
Price usd200,000
Packaging Details standard export packing
Delivery Time 120
Payment Terms L/C, T/T
Supply Ability 5sets/m

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Item 1-100 Ton Per Hour Customzied Mango Pulp Production Line Fruit Pricessing Line Input Fresh Mango
Output Mango Pulp Capacity 1-110t/h
Feature Turnkey Project Packing Aseptic Big Bag
High Light

Mango Processing Line Customized


1Ton Per Hour Mango Processing Line


100Ton Per Hour Mango Processing Line

Leave a Message
Product Description

1-100 Ton Per Hour Customzied Mango Pulp Production Line Fruit Pricessing Line


Stone removing machine

Ø Capacity:1t/h

Ø Widely applicable to stone fruits such as mango and peach;

Ø A sieve to be removed, according to the size of the fruit kernel;

Ø Install anti-shattering nuclear devices;

Ø Door cover secondary safety protection;

Ø Fully automatic completion of stone fruit juice, pit, slag removal procedures;

Ø Allotments power (KW) 11

Ø Speed (r/min) Speed of nucleus removal 410r/min

cache jar

Ø 304 stainless steel material;

Ø Single-layer upper and lower cone-bottom structure;

Ø Stainless steel plate thickness: 3mm

Ø With stirring

Ø The outer surface adopts wire drawing board;

Ø High and low liquid level control;

Ø Conical top and cone bottom structure, including manhole, vent cap, cleaning ball, water inlet, material inlet and outlet, visual sight glass;

Ø The inlet and outlet adopt anti-foam and anti-swirl structure;

screw pump

Ø Output: 1T/h;

Ø Food grade rubber stator; mechanical seal with thruster

Ø Outlet flange connection;

Ø Outlet pressure 0.6MPa

Double beater + platform

Ø Processing capacity: 1T/h;

Ø Horizontal structure, double station;

Ø Suitable for beating all kinds of broken fruits and vegetables;

Ø The blade speed is steplessly adjustable;

Ø The mesh diameter is Φ0.8mm-Φ1.2mm, each set is used to remove the peels in the jam, and at the same time, the product is refined to make the particles fine and uniform;

Ø The drive adopts frequency conversion motor;

Ø The beater body is made of 304 stainless steel;


Company Profile

SSS Food Machinery Technology Co., LTD is a leading supplier of food processing equipment in China.We are able to provide complete turnkey project solution for intelligent processing equipment.We are mainly specialized in fruit and vegetables processing line for puree,juice,jam,dried fruit, powder,fruit wine & vinegar,fermented beverage,ect .And dairy processing line.Also the related stand-along equipment with superior quality,competitive price and professional service.SSS has a complete team from R&D design, production, quality inspection,process guidance, with more than 20 years’ professional experience in this field.
