Commercial Automatic Orange Juicer Machine 1t/H Or As Required

  • Commercial Automatic Orange Juicer Machine 1t/H Or As Required
Place of Origin china
Brand Name sss
Model Number customzied
Minimum Order Quantity 1
Price usd300,000
Packaging Details standard export packing
Delivery Time 120
Payment Terms L/C, T/T
Supply Ability 10sets/y

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Item Commercial Automatic Orange Juicer Machine Factory Price FRUIT PROCESSING LINE Input Fresh Orange
Output Orange Juice Capacity 1t/h Or As Required
Product Packing Bottle, Bag, As Required Feature Turnkey Project
High Light

Commercial Automatic Orange Juicer Machine

,

1t/h Automatic Orange Juicer Machine
Leave a Message
Product Description

Commercial Automatic Orange Juicer Machine Factory Price FRUIT PROCESSING LINE





Commercial Automatic Orange Juicer Machine 1t/H Or As Required 0



Commercial Automatic Orange Juicer Machine 1t/H Or As Required 1





Item
Specification
1
Bubble cleaning machine
Ø capacity:1T/H；
Ø SS304, Thickness 2.5mm；
Ø SS304 square steel for frame
Ø Equipped with cleaning hand hole, sewage outlet and overflow outlet;
Ø Using 304 stainless steel scraper for conveying and lifting;
Ø Motor mechanical stepless speed regulation motor;
2
Picking, Conveyor
Ø capacity:1T/H
Ø SS304, Thickness
Ø The belt is food grade;
Ø SS304 square tube for Main frame;
Ø Conveyor belt: food grade PU material;
Ø Motor: Mechanical stepless speed regulation motor
3
Bubble rinse machine
Ø capacity:1T/H；
Ø SS304, Thickness 2.5mm；
Ø SS304 square steel for frame
Ø Equipped with cleaning hand hole, sewage outlet and overflow outlet;
Ø Using 304 stainless steel scraper for conveying and lifting;
Ø Air pump: 5M3/min;
Ø Motor mechanical stepless speed regulation motor;
4
lifting
Ø Output: 1T/h
Ø Smooth scraper baffle, water seepage structure;
Ø Made of 304 stainless steel;
Ø 304 square tube frame;
Ø Adopt chain drive mechanism;
5
Peeling and juicing machine
Ø widely used for peeling and juicing (beating) of tropical fruits such as pineapple (pineapple), passion fruit (passion fruit),
guava, papaya, citrus, banana and so on.
Ø power: 7.5KW;
Ø capacity: 1T/H;
Ø The parts in contact with the material are made of stainless steel.
6
Storage tank
Ø Capacity: 300L
Ø 304 stainless steel material;
Ø The outer surface adopts wire drawing board;
Ø High and low liquid level,
Ø moving cover,
7
Material pump
Ø Output: 0.5T/h;
Ø Head 24m;
Ø With guide wheel;
Ø Stainless steel material;
Ø Power: 1.1kw;
8
Refining machine
Ø Output: 0.5T/h
Ø Material 304 stainless steel
Ø Stainless steel mesh aperture 0.3/0.5mm,
Ø Frequency control,
Ø Spiral pusher structure, the slag discharge port adopts gravity induction discharge
Ø Equipped with high-pressure flushing device, high-pressure flushing can also be performed during equipment operation;
Ø Feeding method: pumping
Ø Screen size:Ф300*620mm
Ø Power: 5.5kw
