HPP High Pressure Processing Machine For Sterilizing

  • HPP High Pressure Processing Machine For Sterilizing
Place of Origin China
Brand Name sss
Model Number customized
Minimum Order Quantity 1
Price 485294
Packaging Details standard exporting package
Delivery Time 80-120days
Payment Terms L/C, T/T
Supply Ability 10set/y

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Item HPP High Pressure Processing Chamber 57L
Max Working Pressure 600mpa Capacity 200-300L/H
Leave a Message
Product Description

HPP High Pressure Processing Machine For Sterilizing



Equipment specification









item

 specification
material Special alloy stainless steel, compliant with ASME U3 material requirements in the United States

Ergonomic approach



Horizontal design, in line with ergonomics, makes loading and feeding more convenient;

Horizontal design helps with any food line connection, convenient and hygienic
Feeding/Unloading Automatic loading and unloading system enables HPP equipment to be automated

Safety indicators



The equipment adopts prestressed steel strip winding technology to ensure safe operation under ultra-high pressure conditions of 600MPa fully stable.

The prestressed steel strip winding structure technology is the most advanced technology for manufacturing ultra-high pressure vessels and large-scale pressure equipment



Applying prestress to containers and load-bearing frames that bear huge loads through steel strip winding,significantly reducing stress and increasing fatigue strength in the synthesized state, completely eliminating stress concentration

Electricity usage



 Adopting the latest generation of variable frequency control system, significantly reducing electricity consumption and lower energy consumption





Technical parameter

item specification
Max working pressure: 600mpa
Effective volume of working chamber 57L
Capacity: 200-300l/h(based on packing)
Working fluid medium pure water
Increasing pressure time about 240s
Pressure holding time 0-3000s
Pressure decrease after 5min ≤5%(can set automatic pressure replenishment when the pressure drops)
Increase pressure method Reciprocating continuous pressurization
Pressure relief method Instantaneous automatic pressure relief
dimension About 8700*4500*3000mm
weight About 18t





HPP High Pressure Processing Machine For Sterilizing 0
